aluminium sheet for curtain wall panel | aluminium sheet for curtain wall panels

Aluminium curtain wall panel is widely used for architectures  to instead of other metals now, due to its nique texture, rich color and long lasting.. Aluminum sheets for curtain wall supporting structure system to share the role of the main structure of the building, and can have a certain displacement capacityAlloy 3003,5052 and 5005 have a strong durable properties, so they are considered to be the mainly alloy materials.
The Aluminium Sheet has the property of light weight, high strength, easy-forming and excellent appearance. Coated with PVDF or PET, the property of anti-wind, anti-light and duration will be highly strengthened. Aluminium Sheet for Curtain wall panels

Grade 1050,1060,1100,3003, 5005,5052
Temper H14, H24, H32,H112
Thickness Range(mm) 1.0-6.0mm
Width (mm) 1000-2650mm
Surface Treatment Mill finished
Payment terms: 30% deposit+T/T or L/C
Delevery time: 20~25 days after deposit received
Packaging details: Wooden pallet,stand sea-worthy
Sample: 1~3 pcs Available
Port of loading: Any port in China

Application
curtain wall, pillar, balcony, surface decoration of partition,interior decoration, advertising board, dashboard, etc.
Aluminium Sheet/Coil for Curtain wall panel
Alloy Temper Specification(MM)
Thickness Width Length
3003, 5052 H14, H24, H32 1.0~4.0 1200-2600 2000-6000 Or Coil
5005 H14, H24 1.0~6.0 1000~2600 6000 Or Coil
3003, 5052 H112, H14, H32 3.0~6.0 1800-2600 2000-10000 Or Coil
Aluminium Sheet/Coil for Roofing tiles
Alloy Temper Specification(MM)
Thickness Width Length
3004, 3005, 5005 H14, H32 0.3-3.0 1200-2400 2000-6000
Or Coil
Aluminium Coil for Ceiling
Alloy Temper Specification(MM)
Thickness Width Length
1100, 3003, 3005 H14, H16,H24, H26 0.3-1.0 1000-1600 Coil
